Entwicklungsbüro Stresing: Line scan camera

Special offer - 2nd grade IR line cameras

Non cooled 2nd grade IR Line cameras with Hamamatsu- Sensor G9204D.
2nd grade: max. 2% of the pixels are out of specs (max. 10 defective pixel, usually 1-2).

Specs:
Max. exposuretime at room temperature:	2 secs.
Spectral range	0.9 to 1.7 µm
Pixel no.	512
Pixel size	25 x 500 µm
Pixel clock	500 kHz
Line rate (max.)	900 Hz

Cameras 16bit - Series 2000 @ 0.5 MHz
CCD - linescan camera (Ha : G9204-512) 512x 1 pixel (25x 500 µm)	4400.00 €

Special offer - Extended IR line cameras

Cooled IR Line cameras with Sensor Unlimited - Sensor SU512LDB.
max. 3% of the pixels are out of specs (max. 15 defective pixel).

Specs:
Max. exposuretime at max. cooled temperature (-15°C):	1 secs.
Spectral range	1.1 to 2.2 µm
Pixel no.	512
Pixel size	25 x 500 µm
Pixel clock	4 MHz
Line rate (max.)	7 kHz

Cameras 16bit - Series 2000CV2 @ 4 MHz
CCD - linescan camera (SU512LDB-2.2T2) 512x 1 pixel (25x 500 µm)	19500.00 €

Prices and availability subject to change. Please ask for detailed offer.
